BSCL

Flexibility for a Wide Range of Applications

The BSCL Compact Line ball rail system is designed to meet the needs of a broad range of standard industrial applications. With top or bottom mounting options, fully interchangeable runners and rails, and rail lengths of up to 50 metres, BSCL gives machine designers the flexibility to adapt the system to their specific requirements.

BSCL

Reliable Performance Based on Proven Rexroth Technology

BSCL combines Bosch Rexroth’s proven engineering expertise with a solution optimized for medium-load applications. An enhanced sealing and lubrication concept, high durability, and reliable operation in demanding environments help maximize system uptime while reducing maintenance requirements throughout the product lifecycle.

BSCL

Optimized Cost-to-Performance Ratio

Designed for projects where performance and cost efficiency matter, BSCL delivers the trusted quality of Bosch Rexroth at an attractive price point. Easy rail machining, simplified installation, fast configuration, and global product availability help reduce engineering effort, shorten lead times, and optimize overall project costs.

Do you want to learn more?

Rexroth linear guides are used across a wide range of industries, including machine tools, medical technology, food and packaging, wood processing, electronics, and battery production. With a broad portfolio of proven solutions, they enable fast configuration, global availability, and cost-effective machine designs tailored to specific application requirements.

Learn more

Why BSCL?

BSCL

Flexibility, performance and price

The BSCL ball rail systems combine proven Rexroth quality with an attractive price-performance ratio. Thanks to flexible configuration and a wide range of applications, they provide an economical solution for many standard applications.

Linear Motion Selector

Want to configure a linear guide?

Use the free Linear Motion Technology Selector. With the selector, you can quickly find the right linear guide for your application, including technical data, CAD models and suitable accessory components.

Linear Motion Technology Selector
Linear Motion Technology Selector

Product information

Advantages at a glance

  • Versatile: for standard applications in Rexroth quality
  • Economical: very good price/performance ratio
  • Practical: easy end machining, shorten without help
  • Flexible: can be combined in anyway in the series, rails and runner blocks can be replaced individually
  • Available: easily configurable, quickly delivered via worldwide Bosch Rexroth sales network
  • Durable: extended sealing and lubrication concept

Technical key data

  • Sizes: 15 to 45
  • Load capacity: C50 dyn up to 99,800 N
  • Max. speed: 5 m/s
  • Max. length: 50 m
    • one-piece rail 4000 mm
    • multi-section rail from up to 15 parts
  • Accuracy classes: N, H and P
  • Preload classes: C0, C1 and C2

Typical applications

  • Automation
  • Secondary axes
  • Woodworking
  • Robot systems
  • Electronics industry
  • Solar
  • Battery manufacturing
  • Printing industry
  • Plastics technology
