Smart Function Kit for pressing and joining applications

Smart Function Kit for pressing and joining applications

Flexible, compact and future-oriented.

Implement standardized joining applications
quickly and efficiently

Whether it be assembly, joining, forming, measuring or testing – the Smart Function Kit is suitable for many standardized pressing and joining applications with forces from 2 to 30 kN. The modular kit combines mechanical and electrical Rexroth components as well as software - the perfect basis for system integrators or end users with process Know-how.

Flexible, compact and future-oriented

Benefit from easy product selection, configuration and commissioning. Furthermore, the Smart Function Kit can be connected via open interfaces and conveniently monitored on a tablet. This maximizes transparency, reduces downtime and increases your productivity.



Smart Function Kit for pressing and joining applications
  • Electromechanical cylinder, servo motor and force sensor

    Electromechanical cylinder, servo motor and force sensor

    Compact, for a variety of pressing and joining applications

  • Servo drive with industrial PC and network connection

    Servo drive with industrial PC and network connection

    I4.0-capable, can be integrated into higher-level systems

  • Browser-based, intuitive Web HMI

    Browser-based, intuitive Web HMI

    For commissioning, process configuration, operation and process analysis

Electromechanical cylinder, servo motor and force sensor

Electromechanical cylinder, servo motor and force sensor

Compact, for a variety of pressing and joining applications

EMC series electromechanical cylinder with freely configurable stroke up to 400 mm

MS2N series servo motor with absolute encoder and brake

Optional: Force sensor with DMS technology for cost-effective and robust force measurement

Servo drive with industrial PC and network connection

Servo drive with industrial PC and network connection

I4.0-capable, can be integrated into higher-level systems

IndraDrive HCS01 servo drive with integrated IndraMotion MLD PLC and STO safety function

Series PR21 Industrial PC, Linux operating system, software and web server with HMI. I4.0-capable: connection via OPC-UA, data access via ReST

Fieldbus connection: Profinet, Ethernet IP, EtherCAT, Sercos III

Browser-based, intuitive Web HMI

Browser-based, intuitive Web HMI

For commissioning, process configuration, operation and process analysis

Wizard for easy commissioning

No programming knowledge necessary (zero programming)

Easy integration into higher-level control and IT infrastructure

Program creation in seconds

Drag & drop process configuration

One system – multiple applications

Assembly and joining

Smart Function Kit - Applications assembly and joining

Forming

Smart Function Kit - Application Forming

Testing

Smart Function Kit - Application Testing

One mechatronic solution – numerous benefits

Easy product selection

Easy product selection

  • Preselected mechanical, electrical and software components are combined in various kits for forces from 2 to 30 kN.
  • All components from a single supplier – with proven Rexroth quality.

Product selection with LinSelect
Product selection with LinSelect
Plug & Produce

Plug & Produce

  • Delivered in a single package, including preinstalled operating software.
  • Automatic parameterization of the servo drive.
  • Few interfaces: servo drive with integrated motion control.

Zero Programming

Zero Programming

  • No programming knowledge required.
  • Simple and logical configuration of the process and the evaluation elements.
  • Browser-based HMI, can be used on various end devices.
  • Modern and intuitive design.

Technical Data

System overview

  • Nominal force 2-30 kN
  • Protection class mechanics IP54 control cabinet IP20
  • Stroke individually configurable up to 400 mm
  • Force measuring sensor with DMS technology
  • Servo drive with STO safety function

Technical Data
Technical Data
